Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker

8W/20W/25W/30W Portable Laser Marker 70mm/100mm Logo Printing Laser Engraving Machine for QR Text

Precise Marking Capabilities, Our 8W/20W/25W/30W Portable Fiber Laser Engraver offers exceptional precision with a marking range of 70x70mm/100x100mm. Utilizing a high-precision two-dimensional scanning system, this fiber laser marking machine guarantees a line width of just 0.03mm and repeat positioning accuracy of 0.01mm. Ideal for both metal and non-metal materials, including gold, silver, copper, steel, paper, plastic, and leather, this laser engraver for metal ensures impeccable results every time.

Inquiry

Write a Review

Portable Handheld Laser Marking Machine Laser Engraver

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 7

Third-party Authoritative Certification(CE, FCC-SDOC, FDA， MSDS, ROHS, etc),Small and Lightweight. Easy to Carry, One-click for Marking, Can be Operated Outdoors.110V/220V Plug-in Version/Rechargeable Lithium Battery Version. Flexible and Portable.

Advantages

Core Advantages

Portable design

Body design: small and lightweight, the whole machine only weighs 6.8Kg; Handheld operation, flexible operation;

Power supply design

1. 220V mains version: plug-and-play, convenient and fast; 2. Lithium battery version: battery detachable design, Charging mode: offline or built-in; With a backup battery, you can last forever.

Touch screen design

8-inch fully bonded LCD screen, one-key trigger. It can be used for multiple purposes in one machine, and the hardware is diversified and compatible;

Configure the Linux system

Using 8-core processor, configuration security level, high performance, stable response.

Technical data sheet
Laser	Fiber laser generator	Output power	8W、20W、25W、30W
Marking range	70×70mm、100×100mm(Optional)	Deflection seismic mirror	High-precision two-dimensional scanning system
Laser wavelength	1064nm	Focus the lens	130mm
Marking speed	≤7000mm/s	Master control	Integrated motherboard, 8-inch capacitor fully bonded to the screen
Operating system	Linux system	Marking type of engraving	Redlett Positionen, Foxin
Line width	0.03mm	Repeatable positioning accuracy	0.01mm
Targeting method	Red light positioning, focusing	The number of engraved character lines	Any line within the valid marking range
Tenon Benn Gravid Charak Tryins	800 characters (related to material and printed content)	Font	Chinese and English, numbers, Chinese Traditional and other standard fonts
File format	BMP、DXF、HPGL、JPEG、PLT	Barcode	CODE39、CODE128、CODE128、OR
Power supply	110V/220V AC, Lithium(216wh)	Power consumption	145-250W
Operating temperature	0-40°	Total weight	6~6.8KG

Application Cases

It has a wide range of applications in various industries such as electronics, plastics, mechanical components, food, clothing and leather, and pharmaceuticals.

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 9

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 10

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 11

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 12

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 13

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 14

Advantage

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 15

Price advantage, quality assurance

Handhale Aslig Matissim Making Mahin.

Our in-house designers and engineers have produced countless great designs for customers from different

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 16

Infrared positioning, accurate marking

Advanced laser technology is used to achieve fast focus and high-precision marking.

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 17

Lightweight design for flexible use

The whole machine is light and portable, and the component design is flexible; Compatible with multi-brand hardware; Flexibly adapt to a variety of scenarios.

Fiber Laser Engraver Handheld Laser Marking Machine Portable Laser Marker 18

One-touch touchscreen, simple operation

8-inch large screen, one-key touch, simple and smooth operation, easy to use.
