New Laser Marking Machine Manufacturer Company
Product details of the laser marking machine manufacturer
Product Overview
Smida laser marking machine manufacturer is prepared and designed using the optimum quality material and ultra-modern techniques. The superior quality of the product guarantees service life. The laser marking machine manufacturer developed by our company can play a role in various fields. The prospects of this product have been steadily increasing over these years.
Product Introduction
Compared with other ordinary products, the laser marking machine manufacturer produced by Smida has the following advantages.
Full Automatic Laser Marking Machine
CS-60DV
SMIDA is not only a seller of laser marking equipment, but more importantly, it provides customers with comprehensive solutions for laser marking.
Reminder:
Laser marking can mark many products with a wide range of materials. If you have any questions or want to find the equipment you need more quickly, you can click to contact us at any time for direct communication.
Laser Marking Machine Description
Laser Marking Machine Application
Various support materials such as PPA, EMC, PCT, filament, ceramic substrate, and aluminum substrate.
Laser Marking Machine Advantages
The Smida laser marking machine has years of technical strength, fast marking speed, high marking accuracy of 0.03mm, zero consumables, environmental protection, high-quality laser light source, permanent marking effect, and can achieve ultra fine marking.
Laser Marking Effect
Laser marking machine -CS-60DV
● Equipped with a powerful vacuum suction system, it only comes into contact with silicon suction cups and will not damage the material sheets.
● Equipped with high-precision color photoelectric sensors, it can accurately distinguish between the material sheet and the isolation paper, avoiding the material sheet from being sucked away.
● Equipped with a dual hopper feeding system, the machine does not stop when replacing the material pieces.
● Equipped with a multi material box receiving system, replacing the material box does not require stopping the machine, improving work efficiency.
According to different customer requirements, multiple machine configurations are available for selection:
● You can choose between single or double laser marking machines;
● You can choose whether to equip a CCD visual alignment system.
● Other.
| Model | CS-60DV | Product Name | Fully Automatic Laser Marking Machine |
| Laser Type | UV Laser(Fiber optic and CO2 laser optional) | Laser Power | 3-10W |
| Wavelength | 355nm | Laser Brand | Guangbo (optional) |
| Marking Range | L60-160, W40-60mm | Laser Cooling Method | Air cooling/Water cooling |
| Marking Efficiency | 300-2000 pcs/h (depends on marking materials) | Positioning Accuracy | ±0.03mm |
| Repeatability Accuracy | ±0.03mm | Standard Marking Line Width | ±0.02mm (depends on marking materials) |
| Minimum Character Height | 0.08mm | Galvo Marking Speed | ≤7000mm/s |
| CCD Resolution | 5 million | Feeding Tray Capacity | 4-8 pcs |
| Marking Software | Jinchenzi/Dazhu | Power Supply | AC220V, 50Hz/60Hz, 2.5kW |
| Weight | 700kg | Overall Dimensions | L1660*W1100*H1720mm |
FAQ
Company Introduction
Shenzhen Smida Intelligent Equipment Co., Ltd., located in shen zhen, specializes in the production and processing of planetary centrifugal mixer,laser marking machine,laser cutting machine. Smida strives to provide professional services to meet customer demand and create great value for customers. With rich experience and exquisite technology, we are looking forward to building good cooperation with partners from all walks of life and creating a better tomorrow!
